- Food-safe coating RAL 9001
- Rollers made of hardened steel
- Variable quick adjustment of roller distance
- infinitely variable for Maltman 110, 150
- finely for Maltman 220 - 550
- Optional: Scale for the determination of crushing gap
- Dosing slider
- Rear panel for wall mounting
- Ammeter
- Hand guard, top and bottom
- Magnetic separator
- Foreign body ejector
- Dosing slider, bulkhead plates, hand guard at top and outlet with hand guard at bottom made of stainless steel
- Central lubrication (for Maltmann 400 and 550)
| Máquina | MALTMAN 110 | MALTMAN 150 | MALTMAN 220 | MALTMAN 400 | MALTMAN 550 |
PRODUCCIÓN (Kg/h) |
100 - 150 | 150 - 200 | 300 - 400 | 600 - 800 | 900 - 1100 |
POTENCIA (Kw) |
1,1 | 1,5 | 2,2 | 4 | 5,5 |
VOLTAGE |
MONOFÁSICO/ TRIFÁSICO | MONOFÁSICO/ TRIFÁSICO | TRIFÁSICO | TRIFÁSICO | TRIFÁSICO |
PESO (Kgs) |
64 | 72 | 116 | 144 | 165 |
DIMENSION MOLINO (mm) (h x w x d) |
580X400X330 | 580X400X330 | 600X585X430 | 650X585X530 | 700X585X560 |
DIMENSIÓN TOLVA (mm) (Opcional) |
285x870x520 | 285x870x520 | 300x1025x545 | 300x1025x700 | 300x1025x700 |
CAPACIDAD TOLVA (litros ) (Opcional) |
110 | 110 | 170 | 225 | 225 |
DIMENSIONES PATAS |
1115X1035X675 | 1115X1035X675 | 1230X1120X800 | 1230X1120X800 | 1230X1120X800 |
| ALTURA TOTAL CON PATAS |
1275 | 1275 | 1485 | 1485 | 1485 |
| ATURA TOTAL CON PATAS Y TOLVA |
1560 | 1560 | 1785 | 1785 | 1785 |
