Applications:
Used for beer fermentation at a controlled temperature and at a pressure of up to 3 Bar.
Accessories:
- Isobaric top manway in stainless steel
- Top inspection sight glass
- Digital thermometer from -20 to +40°C
- Certified for pressures up to 3 Bar
- Stainless steel butterfly valve
- DIN clear-outlet connection
- Stainless steel butterfly valve
- Lower DIN outlet for yeast extraction
- Sampling valve
- Cleaning system with CIP spray ball
- Cooling jacket on the tank body and optionally on the conical section
- CO₂ outlet tube with pressure regulator up to 3 Bar, with bubbling device (airlock)
Technical Specifications:
- All parts in contact with the liquid are made of AISI 304 stainless steel sheet (optionally AISI 316)
- Cylindrical body with a 60° conical bottom
- Working pressure regulator up to 3 Bar
- Stainless steel safety valve
- Stainless steel vacuum relief valve
- Insulated jacket with injected polyurethane, 80 mm thickness
- External cladding in 1.5 mm thick stainless steel sheet, welded and polished
- All welds fully polished and passivated, both internally and externally
